Product and Performance
Technical Data
Flow Rate | 12 l/min (bei 2m Förderhöhe) | |||
Delivery Head | 40 m | |||
Suction Lift | 1,5m | |||
Max. Temperature | 50°C | |||
Inlet | 3/8“ BSP IG mit Schlauchnippel Ø14 mm | |||
Discharge | 3/8“ BSP IG mit Schlauchnippel Ø14 mm | |||
Pump Casing Material | Messing | |||
Zahnräder | Bronze | |||
Spindle Material | Edelstahl | |||
Dichtung | NBR Lippendichtring | |||
Voltage Protection | 12 V / 15A | |||
Motor | Bürsten-Dauermagnetmotor | |||
IP Protection | IP 55 | |||
Total Weight | 2,7 kg |
